Archives For Ports

project-walvis-bay-container-710Namibia’s 344 million U.S. dollars container terminal currently under construction in its coastal town of Walvis Bay is 76 percent complete, the Namibian Port Authority (Namport) said Thursday.

According to a statement issued by Namport, the contract is on schedule for completion of most of the works at the end of 2018 with minor works to be completed early 2019.

One of the major components of the projects is the commissioning of four new Ship Container Cranes (STS), making it the first time that these cranes will be deployed in the port of Walvis Bay.

Namport has to date made use of mobile cranes to load and offload containers from vessels.

The 4 STS cranes are expected to arrive from China on February 10, 2018.

The project which commenced in May 2014 with the contractor being China Harbor Engineering Company Limited will have a throughput capacity of 750,000 TEUs (twenty foot equivalent units) per annum.

The new port will also be connected to the existing port’s road and rail networks as well as communication systems. Source: Xinhuanet 2018-02-01

Advertisements

Kaduma Dry Port

On Thursday, 4 January 2018, Nigeria’s President, Muhammadu Buhari, inaugurated the Kaduna Inland Dry Port and warned the Nigeria Customs Service and port officials against frustrating the effective use of the facilities. Inaugurating the facilities in Kaduna, Buhari said the customs and the port officials must make the facilities work and not to frustrate business, commercial and industrial enterprises with unnecessary bureaucracy.

It remains for Customs and Ports officials to make these facilities work and not to frustrate business, commercial and industrial enterprises with unnecessary bureaucracy and inflicting on them delays and hardships, thereby defeating the object of the whole exercise as has happened in the past.

According to him, the hinterland business community has waited for too long for such facility that has tremendous potentials to ease the way of doing international business for the interior based importers and exporters. He said that the development of Inland Dry Ports was an important factor in the nation’s economic development efforts.

As Ports of origin for exports and ports of destination for imports, the Inland Dry Ports will accelerate the implementation of our economic diversification policy. “The concept of Inland Dry Port has gained widespread importance with the changes in international transportation as a result of the container revolution and the introduction of door-to-door delivery of cargo.

It provides importers and exporters located within the nation’s hinterland, especially industrial and commercial outfits, access to shipping and port services without necessarily visiting the seaports. “It also enables them to process clearance of their import cargo and take delivery of their raw materials and machinery close to their places of business.

President Buhari also said that the Dry Ports would provide exporters the much-needed facilities to process, package, consolidate and forward their exports to their customers all over the world without having to physically be at the seaports. According to him, this replicates the port economy in the various centres where the Dry Ports are located inland thereby generating employment and contributing to the ease of doing business.

He said in addition to the Kaduna Inland Dry Port, six other Inland Dry Ports in Ibadan, Aba, Kano, Jos, Funtua and Maiduguri, which had also been gazetted, were at various stages of completion. He congratulated the Kaduna State Government, the Federal Ministry of Transportation, Nigerian Shippers’ Council as well as the hinterland importers and exporters on the inauguration of the facilities.

The president also commended the initiative of Nigerian Shippers’ Council towards promoting the provision of these modern transport infrastructural facilities. He, however, urged the Concessionaires of the other six Dry Ports to emulate the Concessionaires of the Kaduna Dry Port by accelerating work on theirs so as to ensure speedy completion of the projects.

He said that with the full complement of the seven Dry Ports, congestion at the seaport and traffic gridlock in the port complex would be eliminated.

“Consequently, the cost of transportation and cost of doing business will be reduced,’’ he said. He lauded the efforts of the Kaduna state government for facilitating the establishment of Kaduna Inland Dry Port.

According to him, the provision of access roads and other utilities to the Dry Port by Kaduna State Government is worthy of emulation by the other Dry Ports host State Governments.

He urged relevant stakeholders across the public and private sectors, particularly Nigeria Customs Service, Nigerian Ports Authority, Nigerian Railway Corporation, Shipping Companies and Agencies, Seaport Terminal Operators, Clearing and Forwarding Agents, Road Haulers and importers and exporters to utilize the facility optimally. Source: article originally published by Vanguard (Nigeria), 4 January 2018

Port of Shanghai

The port of Shanghai has set a new world record by handling over 40 million TEUs.

On December 10, 2017, Shanghai Yangshan Deep Water Port, the world’s biggest automated container terminal, started trial operations.

Shanghai Port started container handling in 1978 with a capacity of 7,951 TEUs. In 2010, the port overtook the Port of Singapore to become the world’s busiest container port, and in 2011 throughput exceeded 30 million TEUs. In 2016, Shanghai set a record by handling over 37 million TEUs.

Shanghai aims to become China’s leading international shipping, aviation and railway hub by 2040. The city has also set a goal of handling 45 million TEUs in Shanghai ports by 2040. Shanghai Yangshan deep water port and Shanghai Waigaoqiao Port will be central to achieving the target, along with other ports including Hangzhou Bay and Chongming Island. Source: Maritime Executive, 1 January 2018

Shanghai Yangshan Deep-Water Port’s Phase IV container terminal started its trial operations last Sunday. The 550-acre, $1.8 billion facility is the latest expansion of the Port of Shanghai’s complex on Yangshan Island, which has deeper water than the port operator’s mainland terminals.

The Port of Shanghai is already the busiest for container traffic in the world, handling a record 37 million TEU in 2016, and the new automated Phase IV terminal will cement its leading position with an additional seven berths and 4-6 million TEU of capacity. Phase III began operations in 2008, but the global financial crisis delayed construction of the long-planned Phase IV until 2014.

According to Chinese state media, Phase IV is the world’s largest automated container terminal, with computer-controlled bridge cranes, AGVs and rail-mounted gantry cranes. All of the equipment is Chinese-made, and the facility also uses a Chinese-designed automated terminal management system. About 100 out of a total of 280 pieces of the automated equipment have already been delivered and are in testing.

“The automated terminal not only increases the port’s handling efficiency, but also reduces carbon emissions by up to 10 percent,” said Chen Wuyuan, president of Shanghai International Port Group, speaking to Xinhua.

Yangshan is the biggest deepwater port in the world. Phase I was finished in 2004, and the following year construction wrapped up on a 20-mile, six-lane bridge to connect the facility to the mainland. Extensive land reclamation allowed for the construction of Phases I through III on new ground adjacent to the islands of Greater and Lesser Yangshan, which were previously home to small fishing communities.

The port handles about 40 percent of Shanghai’s exports, and its operators hope to see it grow as a transshipment hub as well. As of 2016, it operates under a free trade zone status, which speeds up customs procedures and facilitates transferring or storing foreign-origin cargoes. Source: Maritime Executive, 11 December, 2017. Pictures: China State Media

containersThe following was penned by a long-time customs acquaintance Aires Nunes da Costa, who has kindly permitted me to post his article titled “Why unpack containers in Durban if you can have containers at your door step in Gauteng within 24 hours?” which first appeared on LinkedIN.

The Tambo Springs initiative involves creating a significantly improved intermodal capability for the movement of freight to and from Gauteng. This is to be achieved by the operational twinning of the inland port with other seaport, inland and cross border locations. The connectivity i.r.o. these twinned locations is achieved via sea, rail, road and air linkages, ideally involving seamless movement of freight between modes.

The Tambo Springs development incorporates a next generation inland port with a state of the art rail terminal facility designed to be developed in phases, with an ultimate capacity of 1 m TEU’S p.a., as well as, a sprinter freight land bridge.

The key elements are as follows:-

Direct Traditional Rail Link to Durban Harbour

The Tambo Springs Terminal will be linked to the Durban Container Terminal which currently handles the bulk of all container freight moving in and out of Gauteng, via an efficient rail service. The fixed rail infrastructure for this link already exists to the Tambo Springs site. This state of the art Terminal facility is designed to significantly increase the rail capacity for container freight to/from Gauteng, while simultaneously reducing real costs and significantly improving levels of service via:

  • a new technology “greenfields” terminal being more efficient;
  • a reduction of congestion issues in and out of the new inland port due to its location;
    improved efficiency of port operations;
  • having the facility serviced by improved rolling stock commissioned by Transnet;
    Sprinter Freight Rail Link to Ngqura Harbour In the Coega IDZ (Port Elizabeth)

In addition to the direct rail link with Durban harbour, the initial phase of this programme involves the twinning of the Coega IDZ and its adjoining Deep Water Container Terminal at the Port of Ngqura with Tambo Springs. This is to be undertaken by means of a Public Private Partnership type structure which utilizes the Transnet capability between the two locations as well as the participation of SARS.

The service level to be achieved for the movement of the freight via this land bridge has a goal of “24 hours” as opposed to the current 3 to 5 days service level achieved at City Deep. This is to be achieved by capitalizing on the creation of high efficiency intermodal activities integrated with the port functions and feeder network.

Truck Freight Movement

The Tambo Springs Inland Port will function as a multimodal logistics gateway serving the Gauteng Catchment area. It therefore provides ease of movement between individual transportation modes in addition to facilitating manufacturing, warehousing and distribution activities.

The operational plan is therefore designed to accommodate long distance (FTL) truck traffic in addition to regional (LTL) freight movement.

The principle truck markets the inland port will attract include:

  • FTL long distance movement of time sensitive freight from other ports or metropolitan areas. This includes both cross docking and stuffing/de-stuffing facilities within the inland port;
  • Rail/truck (intermodal) movement where product utilizing the rail links is transferred to truck in order to each its final destination;
  • LTL truck and Van short distance movement of freight, including a regional metropolitan distribution function.

The next generation inland port therefore capitalizes both on rail and road transportation modes with a focus on increased movement of long distance freight by sprinter rail.

Intermodal Movement

In order to achieve seamless intermodal movement of freight between sea, rail, road and air transport, it is essential to link Tambo Springs with other inland port and hub locations. The creation of such a twinned Inland Port Network provides a means to effectively participate in the Global Supply Chain in a manner which optimizes both existing and new facilities to enhance capacity. Hence, for example, Tambo Springs would be linked to City Deep via rail and road linkages and to other hub locations in Gauteng and elsewhere.

A principle element of this approach is to create an efficient transportation service between all the individual entry/exit ports providing an improved level of service over and above that provided by a traditional network. The key to this is to rethink existing processes with a focus on efficiency savings in terms of the inbound and outbound process flow at Tambo Springs. This has been incorporated into the operational concept and addresses both operational and customs and regulatory efficiency issues as part of the supply chain. Source: Aires Nunes da Costa (Customs & Excise Specialist)

Hyperloop could be heading to the Middle East, thanks to a new deal signed on Monday between Hyperloop One and port operator DP World. The partnership calls for a feasibility study of how the nascent, ultra-fast transport technology could improve Dubai’s Jebel Ali Port, but both parties hope that’s just the beginning.

The study will look at the possibility of building a Hyperloop to take freight off container ships arriving at Jebel Ali and transport it via the technology’s system of pods moving through pressurized tubes to an inland depot that DP World plans to build further inland.

“By having a system where a box can be taken off a ship and dropped into the tube or pod, we are moving activity that would otherwise be on the island terminal as well as reducing the size of the terminal you need to build,” said Hyperloop One founding board member Peter Diamandis.

The Los Angeles-based startup says a Hyperloop can fit within Dubai’s existing transportation corridors and could reduce freeway traffic by taking cargo transport trucks off roads. DP World says it can even foresee using a “submerged floating Hyperloop” located next to its huge new terminal built on a man-made island. Source: Hyperloop One

Forbes.com hyperloop diagram

Picture courtesy Forbes.com

Hyperloop One, a Los Angeles company working to develop the futuristic transportation technology, has announced the closing of $80 million in financing and said it plans to conduct a full system test before the end of the year.

A Hyperloop would whisk passengers and cargo in pods through a low pressure tube at speeds of up to 750 miles per hour (1,207 km per hour). It has been likened to a mix between the Concorde plane, a rail gun and an air-hockey table.

Early applications could center around ports – possibly replacing the trucks and trains that carry cargo from ships to factories and stores. Some anticipate that it could start operation in Los Angeles, close to some of the biggest port in the U.S.

Hyperloop One builds off a design by Tesla and SpaceX CEO Elon Musk, who has suggested it would be cheaper, faster and more efficient than high speed rail projects, including the one currently being built in California.

A test of the Hyperloop One system was conducted on Wednesday when a car-sized sled powered by electromagnets rocketed to more than 100 miles (160 kph) an hour through the Nevada desert.The sled began on a train track and then was rocketed to 105 miles per hour by electromagnets as electricity was shot into copper coils. After a short ride, the sled ran into a sand trap, sending out silicon sprays. If all goes according to plan, sleds will levitate and carry pods in a test later this year. Gigantic tubes already are scattered around the Las Vegas area test site.

Maglev technology would levitate the pods to reduce friction in the system, which would be fully autonomous and electric powered. Magnetic fields in the tunnel will lift the pod before a “thrust force” is applied, which will then accelerate it to speeds of up to 1230km/h. When the same force is applied for breaking the pod, the system’s battery is recharged through regenerative braking.

Using such a passive levitation system would eliminate the need for power stations along the Hyperloop track, and if any type of power failure occurs, Hyperloop pods would continue to levitate and only after reaching minimal speeds touch the ground, says the company.

The open source technology would, according to the initial “Alpha” design released in 2013, enable travel from the Los Angeles region to the San Francisco Bay Area in 35 minutes, meaning that passengers would traverse the proposed 569 kilometer (354 mile) route at an average speed of just under 962 km/h (598 mph) and a top speed of 1,223 km/h (760 mph).

Hyperloop One CEO Rob Lloyd likened hyperloop technology to the emergence of the U.S. railroad system and the era of prosperity it ushered in.

Lloyd also announced a competition to determine where the first Hyperloop One system should be built, with an announcement expected next year.

Hyperloop One has competition including Hyperloop Transportation Technologies, a crowdsourced company that last month signed an agreement with the Slovakian government to build a hyperloop connecting Slovenia with Austria and Hungary.

Skeptics say real-world challenges ranging from construction permits to making the new technology work mean the costs are likely to be far greater. Source: Martime Executive.

MCA LogoThe UK Maritime and Coastguard Agency has dropped the tolerances it was considering for weighing equipment used to weigh a container for the new SOLAS VGM requirement.

One of the issues that has been holding some terminals back from investing in equipment to weigh containers is the lack of any clarity over the accuracy standards that equipment must meet. SOLAS says only that equipment must “meet the applicable accuracy standards and requirements of the State in which the equipment is being used”.

The UK Maritime and Coastguard Agency (MCA) had been consulting on a proposal for two weighing tolerances for equipment used to generate a Verified Gross Mass (VGM) using method 1 (weighing the container):

  • +/- 400kg up to 20T then +/- 2%
  • +/- 300kg up to 15T then +/- 2%

Sources involved in the process say some port operators and weighing equipment suppliers had expressed concerns these tolerances were unreasonable. MCA has this week issued new guidance on the VGM requirement, including a procedure for applying for approval to use Method 2 (weighing cargo items and calculating the total weight of a container).

The MCA has dropped any requirement for a specific accuracy level, opting instead to set an enforcement level. It stated: “The verified gross mass should be as accurate as reasonably practical taking into account methodology and operational variances. The MCA has set an enforcement tolerance of ±5% or ±500kg, whichever is the greater value to avoid disruption within the supply chain, however this value is for enforcer’s guidance only and it is the shipper’s responsibility to be as accurate as possible”.

Method 1 equipment includes “weighbridges, or lifting equipment fitted with load cells, or other approved weighing equipment to determine a loaded container’s Verified Gross Mass (VGM)”. Unlike other jurisdictions the MCA has not stated that it requires two 20ft containers on a trailer to be weighed separately, or said anything about how the weight of the truck and trailer is to be obtained. It stated only that “Calculations may be used as part of the method 1 process”, so these items do not in fact need to be weighed as part of the VGM process.

With regard to certification and enforcement, the MCA states: “ Method 1 users are required, on request by the MCA or other body, to provide both of the following:

  • Evidence that the weighing equipment has been supplied/maintained for the purpose of determining the VGM of a loaded container and is capable of producing a ticket (electronic record). Each ticket must include the container number, the VGM of the container, and the procedures for, and records of, any calculations which have been made. If this information is produced as an electronic record, it is essential that it is able to be produced without delay as a paper document.
  • Records kept of maintenance and verification (calibration) procedures, including any corrective / remedial actions taken.

The full guidance and other documentation can be found at this link. Source: WorldCargoNews

PSA Singapore Terminals

Two new container berths capable of serving large container ships will be operated by COSCO-PSA Terminal in Singapore in 2017.

COSCO-PSA Terminal (CPT), a joint venture company formed by COSCO Pacific Limited and PSA Corporation, is investing in the new berths, and will move from its current two-berth terminal to three new mega berths as part of a Pasir Panjang Terminal expansion project.

A few of the planned 15 berths in Phases 3 and 4 of the Pasir Panjang Terminal are already operational. The rest of the S$3.5 billion ($2.6 billion) project is scheduled to be completed by the end of 2017, pushing Singapore’s annual container handling capacity to 50 million TEUs.

All the new berths at Pasir Panjang Terminal are designed to be able to handle container ships with capacities larger than 10,000 TEUs.

PSA Singapore currently operates 57 berths at its container terminals in Tanjong Pagar, Keppel, Brani and Pasir Panjang. The terminals at Pasir Panjang are PSA’s most advanced. The berths at Pasir Panjang Phases 3 and 4 are up to 18 meters deep and equipped with quay cranes able to reach across 24 rows of containers to serve the world’s largest container ships. They also feature the latest port innovations such as a zero-emission, fully-automated electric yard crane system.

Singapore is the world’s second busiest container port after Shanghai in China, which took over Singapore in 2010. Source: Maritime Executive

RWG-terminalRotterdam World Gateway says it is the first deep sea container terminal with minimal customs presence in the European Union. Ronald Lugthart, Managing Director of Rotterdam World Gateway,has received the definitive customs permit and AEO certificate for RWG, handed over by Anneke van den Breemer, Regional Director of customs at the port of Rotterdam.

Lugthart said: “Due to the high degree of automation at RWG, the introduction of a 100% pre-announcement procedure for containers and cargo via Portbase and the implementation of simplified customs procedures, over 95% of the administrative process is now completely digitised.

“This means that the administrative process can operate independently of the logistic process at the terminal, enabling fast and reliable handling.”Anneke van den Breemer commented: “As Dutch customs, our goal is to minimise any disruption to the logistic process caused by the required customs formalities. RWG and customs have recently been collaborating intensively.

“At the RWG terminal, optimal use is now being made of the simplified customs procedures. This is in the best interest of all parties: not just of the terminal and customs, but of freight forwarders and hauliers as well.”

By applying these simplified customs procedures, RWG is able to implement a fully automated gate process for road hauliers. This has great benefits for hauliers because no physical customs handling has to take place at the RWG terminal and thus no stop has to be made.

RWG adds that it is the first terminal in the port of Rotterdam to act as an Authorised Consignee, which means the customs transit will be automatically ended upon arrival at the terminal. This gives parties involved extra assurance that this transit has been cleared properly.

In addition to simplified customs procedures, constructive cooperation between customs and RWG has resulted in the establishment of a new scanning facility that is fully integrated into the terminal’s automated logistic process and operates 24/7.

Furthermore, nuclear radiation detection takes place for all truck and rail handling, and a high percentage of the containers arriving and departing by barge will be inspected as well.  Source: WorldCargoNews

Container_crane_and_spreader

Picture: Wikipedia

The Port of Felixstowe has confirmed that it will offer a container weighing service to ensure UK shippers are able to comply with the new SOLAS regulations that come into effect on 1 July 2016

The new SOLAS Chapter VI regulation requiring the shipper (or other named party in the Bill of Lading – normally a freight forwarder/NVOCC) – to supply the shipping line with a verified gross mass (VGM) declaration before the container can be loaded aboard the ship comes into force on 1st July. As widely reported, there is widespread concern that shippers will not be ready.

Commenting on the new service that Felixstowe will provide, Stephen Abraham, the port’s COO, said: “We have met with many customers and from their feedback it is clear that there is still a lot of uncertainty amongst exporters about the new rules.

“The rules have the potential to cause significant disruption to export supply chains. To help avoid this, we have decided to provide a service where export containers can be weighed at the port before being loaded. We will provide further details about how the weighing service will work in good time to ensure all exporters can be compliant by the time the new rules come into force.”

The service at the port will be available to containers arriving either by road or rail. This is important as, through its railheads, Felixstowe is the UK’s largest intermodal rail terminal; 40% of all laden export containers arrive at the port by rail.

To provide the weighing service, Felixstowe will use a spreader twistlock-based system, although the supplier of the system and the number of RTG and intermodal RMG spreaders that will be equipped with it has not been confirmed.

The UK Maritime and Coastguard Agency (MCA), which is the responsible authority for the VGM as regards UK containerised export shipments, requires all weighing equipment used to provide a VGM, whether by Method 1 or Method 2, to be calibrated to within +/- 0.1% of the true mass of the loaded container (Method 1) or by calcuation based on the sum weights of the individual cargo items being packed and associated dunnage, lashing chains, etc (Method 2).

When, at the end of 2010, the International Chamber of Shipping first launched its campaign for all containers to be weighed before ocean carriage, it was assumed that the weighing would take place in ports – naturally, as ports are where most container lifting equipment is based.

However, port operators – including, and not least, Felixstowe – successfully resisted this, which ultimately resulted in IMO formulating Method 2. While the road to IMO arriving at Method 1 and Method 2 is “history,” the key point is that port operators, freed of a legal obligation to weigh loaded export containers, are thereby free to offer a Method 1 weighing service on a commercial basis.

Irrespective of the technology employed, there are several issues around port weighing. What happens if, for example, when the port [any port, not just Felixstowe] weighs the export container for the purpose of providing the VGM and finds that the weight made the container illegal for road carriage to the port? Does the port have a legal obligation to inform the road traffic authorities [the police in the UK]; or is the onus on the shipping line, whose customer the “offending” shipper/NVOCC is?

That information is also “historic,” in the sense that in order to weigh the overloaded container in the port, it must be assumed that the truck arrived safely at the port, and that particular (unique) illegal truck trip to the export port has gone forever. The remaining problem, however, is that the VGM provided by the port may indicate that the weight of the container makes it illegal for on-carriage by road or rail in the port of unloading.

Asked to comment on this by WorldCargo News, Paul Davey, Head of Corporate Affairs, Hutchison Ports (UK), made a crucial point. “As regards legality for road carriage in all possible overseas destinations, we [at Felixstowe] would not know, for example, whether the container will leave the port of destination or is unstuffed in the port. If it leaves the port [without being unstuffed] we won’t know whether the on-carriage would be by road, rail or any other mode, so there is nothing we could do.”

This is key as it throws the real responsibility for enforcing the VGM on the carriers, who demanded compulsory weighing in the first place. They will be under a legal obligation not to accept a loaded container unless it has VGM documentation.

It follows logically that carriers know the VGM mass of all loaded containers they ship. If, on the way to destination from the port of import, due to gross overloading of the container, the truck jackknifes or overturns, with all the safety risks that entails, the carrier could be liable and open to criminal prosecution.

Thus, there can be no question of “shipper appeasement,” but it could end up in a lawyer’s free-for-all involving anyone providing the VGM if it transpires that the VGM data were incorrect. Suppose, for example, the carrier relied on VGM data provided on a commercial basis by the port of export and it transpired, following a road accident investigation in the country of import that the real weight exceeded the VGM and likely caused the accident.

As to the commercial possibilities for ports providing a VGM service, Felixstowe has not given any information on the price it will charge, but (by way of example) Yarimca in Turkey is advertising US$12 to weigh a container, according to its tariff notice.

Policy responses by port operators will vary enormously according to local context and assessment of risk and benefit. In New York/New Jersey – where loaded containers are mosly imports – Maher Terminals has advised customers that loaded export containers will not be accepted after the July 1st deadline whitout a VGM in advance, as part of the booking process.

PSA Antwerp, which is also offering a VGM service, has stated that it may, at its discretion, “strip and restuff a container so that it complies with the SOLAS requirements. The customer will pay an appropriate compensation to PSA for any such stripping/restuffing of a container and/or determining its VGM.”

The new SOLAS Ch VI imposes no obligation on terminals to weigh containers they unload. All the same, as regards imports, PSA Antwerp says: “If PSA loads a container onto a truck, it can never be held liable for additional expenses and/or fines associated with the (excess) weight of the container/truck combination.

“Any such additional expenses and/or fines will never be borne by PSA and the customer will pay an appropriate compensation to PSA for any such additional expenses and/or fines incurred by it and/or for determining the weight of the container/truck combination.” Source: WorldCargoNews
